Amphenol MIL-C-5015 Connectors MS-A Class Wall Mounting Receptacle ,Amphenol, Connector,circular,MIL C 5015,plug,chassis mount,threaded coupling,6 way, Amphenol 97 (Olive Drab) (MIL-C-5015 Conforming)
Note :
Cable plugs only mate with chassis sockets. Cable sockets only mate with chassis plugs.
Technical specification
Shell Material : Aluminium alloy plated olive drab finish
Insulator : Bonded monobloc neoprene
Contacts : Copper alloy plated silver over nickel
Working Voltage Class A: :500Vac or dc peak
Class Inst: :200Vac or dc peak
Insulation Resistance :5000 MΩ
Contact Resistance :5mΩ
Temperature Rating : -55 to +100°C
